FF502P

Product Details

4 Zone Sounder Circuit Extender Kit

  • Provides four extra conventional sounder circuits with open and short circuit fault monitoring.
  • Compatible with most manufacturers' fire alarm control panels.
  • Supplied on a double gang plate.
  • Basic connection requires four wires: 24 VDC, 0V, Sounder –Ve & Sounder +Ve.
  • Sounder -Ve & Sounder +Ve can be connected at the host panel or any convenient point on a sounder circuit (DO NOT SPUR). 24 VDC and 0V can be derived from the host panel or, alternatively, from an external PSU.
  • If connecting the FF502P to a C-TEC fire panel only three input control wires are required (Sounder -Ve is not required as our conventional panels have a common 0V rail).
  • Fits on standard UK 25mm flush or surface mount back boxes.
